Name: Cartesykj 2CTPB-3-3 4T capacity 2 plates Ultra flat plate brake tester Car Test Line for truck test the brake force
Brand: Cartesy Diagnosis Technology CO.,Ltd
SKU: 2CTPB-10G
Price: 1.00 USD
Availability: InStock

Casa > produtos > Teste de travões >

Cartesykj 2CTPB-3-3 4T capacity 2 plates Ultra flat plate brake tester Car Test Line for truck test the brake force

Lugar de origem:

China

Marca:

Cartesykj

Certificação:

Número do modelo:

2CTPB-10G

Contacte-nos

Peça umas citações

Detalhes do produto

Nome:

Teste de travões de placas planas de luxo

Montagem de carro:

BMW - Europa

Garantia:

12 meses

Nome do modelo:

2CTPB-10G

Porta:

GUANGZHOU

Max. Peso do eixo permitido ((kg):

10.000

Distância de ensaio da força de travagem ((N):

Erro de indicação da força de travagem:

≤ ± 3%

Tamanho do pesador:

610*1500 ((Largura*Longo)

Combinação:

2 placas ((4 placas opcionais)

Fornecimento de energia ((A):

220v 300W

Dimensão ((Longo*Largo*Alta):

2854×1000×58 ((2 paletes)

Termos de pagamento e envio

Quantidade de ordem mínima

1 unidade

Preço

$2,000.00 - $13,836.00/sets

Detalhes da embalagem

Pacote de madeira

Tempo de entrega

20 a 25 dias úteis

Termos de pagamento

L/C,T/T

Habilidade da fonte

300 conjuntos por mês

PRODUTOS CONEXOS

Linha de ensaio do veículo Equipamento de inspecção do veículo Teste da força de travagem 4CTPB-3-4 Teste de travagem de placa ultra plana

Obtenha o melhor preço

BMW Europa Encaixe de Carro 4T Linha de Teste Automotivo Placa Plana Simulação Estrada Plana Super Plana Testador de Freio

Obtenha o melhor preço

116 Instalação de automóveis CTFZ-13B Caminhão Cintura de travagem de travagem de carga Máquina de ensaio de elevação

Obtenha o melhor preço

BMW Europe CTFZ-10B Máquina de ensaio de elevação de carga de cinturão de travagem de rolamento de caminhão 2004-2008

Obtenha o melhor preço

Contacte-nos

Contato agora

Descrição do produto

Cartesykj 2CTPB-3-3 4T capacity 2 plates Ultra flat plate brake tester Car Test Line for truck test the brake force

Product introduction :

The vehicle flat plate test brake line is mainly composed of plate brake tester, which is on the plate simulating the actual flat road. The motor vehicle runs on it at a speed of 5 to 15 km / h, and then implements the braking. The dynamic measurement of the front (or rear) axle braking force, axle (wheel) weight, suspension, sideslip and other items can be completed at one time. Through the different combination of the brake plate, it can also test the brake performance of various motor vehicles such as automobiles, motorcycles, agricultural vehicles, etc. Our company introduces the latest technology from Europe to manufacture the flat brake test bench. It has advanced technology, reasonable design, simple structure, stable performance, convenient use and maintenance, complete functions. It is especially suitable for automobile testing station, repair shop and automobile professional teaching and technical research unit.

Configuration feature:

No need for concrete foundation installation, small occupation of land, convenient installation and commissioning.

No need for 380V power supply, low operating cost, energy saving, saving investment

The plate structure of plate brake tester can be combined in many ways to be suitable for vehicle types and various wheelbases

The design, process and manufacture of the plate of flat brake tester comply with the latest national standards GB21681 and GBT7258

With imported high-precision sensor, fast response, and accurate test. The latest product concept, ultra-thin.

Motor vehicle braking on board, the simulation technology is closer to the actual road conditions, and the test result is more real and reliable

System with a variety of online interface, can match headlight tester and the gas analyzer to form such as multi-function integrated performance test line

Four plates combination can be adopted, which can make the front and rear wheels of the vehicle test at the same time, accurately reflect the brake synchronization of the front and rear vehicles, truly test the brake force characteristic curve and the brake coordination time of the whole vehicle

Technical parameters:

Model	2CTPB-3-4	2CTPB-3-3	4CTPB-3-4	2CTPB-10G	2CTPBH-10
Max. axle-load (kg)	3000kg	3000kg	3000kg	10000kg	10000kg
Braking test range (kN)	10kN	10kN	10kN	35kN	35kN
Sideslip Test Scope (m/km)	0-±10m/km	N/A	0-±10m/km	0-±15m/km	N/A
Braking force error value	≤±3%	≤±3%	≤±3%	≤±3%	≤±3%
Sideslip test precision (m/km)	≤0.2m/km	N/A	≤0.2m/km	≤0.2m/km	N/A
Axle load error value	≤±2%	≤±2%	≤±2%	≤±2%	≤±2%
Weighing plate size	6101500(widthlength)	6101500(widthlength)	6101500(widthlength)	10001800(widthlength)	10001800(widthlength)
Combination	2 plates	2 plates	4 plates	2 plates(4 plates optional)	2 paltes(4 plates optional)
Testing speed (km/h)	5-10km/h	5-10km/h	5-10km/h	5-10km/h	5-10km/h
The power supply	220v 300w	220v 300w	220v 300w	220v 300w	220v 300w
Plate size (mm)	2554×610×50	1760×610×50	4314×610×50	2854×1000×58(2 paltes)	2440×1112×100

Cartesykj 2CTPB-3-3 4T capacity 2 plates Ultra flat plate brake tester Car Test Line for truck test the brake force 1

Cartesykj 2CTPB-3-3 4T capacity 2 plates Ultra flat plate brake tester Car Test Line for truck test the brake force 2

Cartesykj 2CTPB-3-3 4T capacity 2 plates Ultra flat plate brake tester Car Test Line for truck test the brake force 3
